P3.9 Outdoor LED Screen
The most-ordered pixel pitch for outdoor events, sport and rental. 500 × 1000 mm cabinets, Novastar control, daylight-readable brightness. Built to your size and shipped DDP to your door.
From US$100 — final price depends on your size, pixel pitch and finish. Contact us for an exact quote.
P3.9 (you will also see it written P3.91) has become the default pitch for outdoor event screens, and the reason is simple economics: it is the coarsest pitch that still looks sharp from 4 metres away. Go finer and you pay for detail your audience cannot see. Go coarser and the picture falls apart when people walk up close.
EKINTRY manufactures P3.9 outdoor screens to order in 500 × 1000 mm rental cabinets. You tell us the size; we build the wall, pre-install the receiving cards, match it with a Novastar processor and ship the whole package in flight cases, customs paid, to your country.
Where P3.9 outdoor screens get used
- Festivals, fan zones and outdoor sports viewing.
- Rental and AV companies that need one versatile pitch.
- Stages and concerts filmed on phones and broadcast.
- Mobile event operators working from a van or trailer.
P3.9 technical specifications
These are the working specs of our P3.9 outdoor rental panels. The cabinet is the industry-standard 500 × 1000 mm format, so a wall of any size assembles from the same building block: a 4m × 2m screen is 16 cabinets, a 6m × 3m is 36.
What comes in the package
A quoted EKINTRY P3.9 screen is a complete, ready-to-run system, not a pile of panels. A typical order includes:
- P3.9 outdoor LED cabinets, 500 × 1000 mm, with Novastar A5S Plus receiving cards pre-installed.
- Novastar video processor sized to your wall (VX400 Pro for screens up to ~2.6 million pixels).
- NovaLCT and ViPlex Express control software, configured before shipping.
- Ground standing frames, hanging bars or truss connectors, depending on your installation.
- Spare LED modules and power-supply boxes with 5-year warranty support.
- Wheeled flight cases, 6 panels per case, ready for van transport.
- Power and signal cabling for the full wall.
Three ways to install it
Ground support is the most common setup for events: the screen stands on its own frames on a patio, lawn or hardstanding, with no structural work, and a two-person crew can assemble or strike it in well under an hour once practised. For stages, the same cabinets hang from truss with standard rigging bars. For permanent advertising positions, the cabinets bolt to a steel wall frame instead.
Viewing distance: where P3.9 wins and where it loses
P3.9 resolves cleanly from about 4 metres. If your closest viewers stand nearer than 3 metres, a P2.5 indoor-style pitch will look noticeably sharper and is worth the premium. If everyone watches from 6 metres or more, P4.8 shows the same content for less money. Most event screens live exactly in the 4–15 metre band, which is why P3.9 outsells everything else.
RV or XS cabinet: pick by how often the screen travels
We build P3.9 in two cabinet series. RV is the value option: same LEDs, same image, more internal cabling, a little slower to service. XS is the touring option: integrated power box, power and signal through connector pins, fewer cables to fail and faster fault-finding on site. Buyers who rebuild the screen every weekend tend to choose XS; buyers with a semi-fixed screen or a tight budget take RV and never regret it.
What a real P3.9 screen cost
A UK customer ordered a 4m × 2m P3.9 outdoor screen from us for live sports viewing in 2026: 16 cabinets, VX400 Pro processor, ground stands, spares and flight cases came to about US$11,000, with DDP shipping from Shenzhen to the UK quoted at US$1,950 by sea or US$2,360 by air. Larger walls scale roughly with area; the control system and freight grow slower than the panel count, so bigger screens cost less per square metre.
| Spec | Value |
|---|---|
| Pixel pitch | 3.91 mm (~65,000 LEDs/m²) |
| Cabinet size | 500 × 1000 mm, die-cast aluminium |
| Module size | 250 × 250 mm, front/rear serviceable |
| Brightness | ≥4,500 nits, daylight readable |
| Refresh rate | ≥3,840 Hz, clean on camera |
| Protection | IP65-rated outdoor cabinet design |
| Input voltage | AC 100–240 V, 50/60 Hz |
| Control | Novastar A5S Plus receiving cards |
| Recommended viewing | 4 m and beyond |
| Screen size | Cabinets | Resolution at P3.9 | Typical audience |
|---|---|---|---|
| 2m × 2m | 8 | ~512 × 512 px | 20–50 people |
| 3m × 2m | 12 | ~768 × 512 px | 50–100 people |
| 4m × 2m | 16 | ~1024 × 512 px | 80–200 people |
| 6m × 3m | 36 | ~1536 × 768 px | 200+ people |
| Pixel pitch | Recommended distance | Best for |
|---|---|---|
| P2.5 | 2.5 m+ | Close viewing, premium detail |
| P3.9 | 4 m+ | Outdoor events, sport, rental |
| P4.8 | 5 m+ | Larger outdoor viewing areas |
| P6 | 6 m+ | Advertising & long-distance viewing |
Delivered project: 4m × 2m P3.9 in the UK
| Client type | Outdoor sports-viewing / hospitality customer |
|---|---|
| Country | United Kingdom |
| Application | Live match screening, daylight into evening |
| Screen size | 4m × 2m (16 × 500 × 1000 mm cabinets) |
| Control | Novastar VX400 Pro + A5S Plus cards |
| Installation | Freestanding on ground stands |
| Package price | ≈US$11,000 + DDP freight to the UK |
Why this solution worked: Guests watch from 4 metres back and further, exactly the band P3.9 is made for. The customer got a daylight-readable picture of the match without paying fine-pitch money, and the flight-case package moves between venues in a van. Read the full write-up on the case study page linked below.
Send us your project details
To recommend the right screen size, pixel pitch, cabinet type and shipping, please send us:
- Screen size, or crowd size and space.
- Closest viewing distance.
- Indoor or outdoor, and portable or fixed.
- RV or XS cabinet (how often it travels).
- Budget range and destination country.
Frequently Asked Questions
What is a P3.9 outdoor LED screen good for?
Outdoor events, sport, festivals and rental work viewed from about 4 m or more. It is the most popular outdoor-event pitch because it balances sharpness against cost better than anything finer or coarser.
What is the difference between P3.9 and P3.91?
Nothing in practice. The true pitch is 3.91 mm; some makers round it to 3.9. The panels, resolution and price class are the same.
How bright is a P3.9 outdoor screen?
Our P3.9 outdoor panels run at 4,500 nits or more, which keeps the picture readable in direct daylight. Indoor panels, for comparison, are typically 800–1,200 nits.
Is P3.9 weatherproof?
The cabinets are IP65-rated outdoor designs, built to run in rain and dust. Like any outdoor screen, they still need sensible cabling and wind-rated structures for permanent installs.
How many cabinets do I need for my screen size?
Each cabinet is 0.5 m wide and 1 m tall. Multiply the width in metres by 2 and the height in metres by 1: a 4m × 2m screen is 8 columns × 2 rows = 16 cabinets.
P3.9 or P4.8 for my event?
P3.9 if your closest viewers stand 4–6 m away or you show detailed content like sport with tickers. P4.8 if the audience is consistently 6 m or further, where it delivers the same impact for around 15–20% less.
